Description
LS Electric H100 frequency inverter for pumping, ventilation and HVAC
Three-phase 0.75-18.5KW (200-230V)
Three-phase 0.75-90KW (380-480V) (110 to 500kW, check availability)
HIGHLIGHTED APPLICATIONS (Special firmware):
– BOMBEO WITH MULTIMASTER CONTROL (Up to 8 variators)
– CONTROL MPPT SOLAR SOLAR [See H100 Solar datasheet]
· V/f control, slip compensation
· Optimized and reduced size
· Side-by-side installation separation 2mm (up to 30kW)
· Overload capacity: 120% for 1 minute (Normal Duty)
Specialized functions for pumping and ventilation:
– Control of multiple motors (up to 8)
– Time function: Real-time clock (RTC)
– Flow compensation
– Smooth pipeline filling operation
– Start ramp and end ramp
– Modified deceleration ramp for valve
– Pump cleaning function
– Load tuning (current and power)
– Fire mode function (fire mode)
– Energy savings counter
– Sleep and wake up function with integrated reinforcement
· Special LCD console for HVAC applications
· Solar pumping: MPPT control and pressure
· Integrated DC bus EMC/Inductance filters (depending on models)
· Protection rating: IP20 (Optional UL NEMA Type 1 protection kit)
· Integrated communications: BACnet, Modbus-RTU, LS Bus, Metasys N2 (Optional: LonWorks)
